Exit Sign | Running Man [LEDRM]

Exit Sign | Running Man [LEDRM]

https://www.lightfixtureindustries.com/web/image/product.template/1868/image_1920?unique=e709d7f
Introducing Canada Approved Running Man LED Exit Sign sophisticated and practical solution that seamlessly combines quality LED illumination with modern soft corner styling. This attractive exit sign is not only eye-catching but also incredibly easy to install and versatile, making it an ideal choice for a wide range of applications. Designed to have interchangeable pictograms to properly mark path of egress. Available in white and black housing.

$ 45.00 45.0 USD $ 45.00

Not Available For Sale

  • Letter Color
  • Housing Color
  • Operation Type

This combination does not exist.

Contact Us

Download Spec-Sheet:

UL Listed

This item has been tested and meets safety standards imposed by the Underwriters Laboratories (UL).

LED Lighting

This unit uses energy efficient and long lasting LED's.

Battery Included

This unit contains a battery for backup power. The battery must be connected during installation.

FEATURES

  • Approved for Canada Markets
  • CSA Listed meets all requirements in C22.2 No. 141-10
  • Interchangeable Pictrograms
  • 120V-347VAC Operations
  • All LED light! No SLA batteries, uses long lasting NiCads that are very low maintenance
  • Universal mounting canopy for ceiling, wall, and side mount
  • Lightweight with snap-together construction for easy installation
  • LED status indicator
  • Injection molded, impact- and scratch-resistant, corrosion-proof, UL 94 V-0 flame retardant housing
  • Push-to-test switch


SPECIFICATIONS

Dimensions (May Vary by Model)
Height9..05"
Depth2.16"
Length13.5"
Weight4.00 lb

WHAT'S INCLUDED?

  • Exit Sign
  • 4 Pictograms to select from
  • One Blank Faceplate
  • Mounting Canopy, Installation Instructions & Hardware (Inside Unit)
  • NiCad Battery - Must connect the battery after installation


CONSTRUCTION

The LEDRM Exit Sign series is constructed from injection molded thermoplastic ABS housing, plastic enclosure 5VA flame retardant housing.

EMERGENCY OPERATION

Upon failure of the normal utility power, an internal solidstate transfer switch automatically provides uninterrupted emergency operation for at least 90 minutes. The fully automatic solid-state, two-rate charger initiates battery charging to recharge a discharged battery in 24 hours.

BATTERY - BATTERY BACKUP

The LEDRM Exit Sign series is designed with a maintenance-free 3.6V 1000mAh NiCad battery that provides a minimum emergency duration of 90 minutes. Recharge time of the battery is 24 hours.

OPERATIONAL TEMPERATURE

Temperature Ratings
SeriesTemperature
Standard50°F to 104°F

ELECTRICAL COMPONENTS

Universal 120V-347VAC operation. LED display indicates AC/ON. An external push button test switch with battery backup units allows maintenance personnel to quickly determine the operational status of the unit. Unit offers surge protected, solid state circuitry.

INSTALLATION

The LEDRM Exit Sign series is suitable for wall, side or ceiling installation via included mounting plate. Snap together design allows for quick and easy installation.

   Mounting Configurations Explained

   View Installation Instructions

DIMENSIONS
