Emergency Light | Industrial 12 Volt Thermoplastic [EL-HD12]
An efficient and secure 12V Heavy Duty Emergency Light. Includes 12V 12Ah maintenance-free batteries, works on either 120 or 227 VAC.
The EL-HD12 emergency light can be ordered with 2 lamp heads or no lamp heads.
Easily extend your lighting requirements by connecting remote heads to the EL-HD12 unit. The unit will act as the main power source and provide power to the remote heads in case of a power outage.
| Operation Type: Battery Backup + Remote Capable |
This item has been tested and meets safety standards imposed by the Underwriters Laboratories (UL).
This unit produces Incandescent light.
This unit contains a battery for backup power. The battery must be connected during installation.
FEATURES
- UL 924, NEC, OSHA and NFPA 101 Life Safety Code
- Universal 120/277 VAC (60Hz) input
- Compact low profile design in neutral finish
- Optional two adjustable lamp heads
- Environmentally-coated, solid state charger
- Automatic low voltage disconnect (LVD)
- Push-to-test switch
- Charge rate / power-on indicator light
Previous Product Codes: EL-50-HD12
Compatible Battery: B6V12A
Compatible Remote Head(s):
LED: RHB-WPL (Outdoor Use), RHB-L (Indoor Use)
Incandescent: RHR-12V
SPECIFICATIONS
| Dimensions | |
|---|---|
| Width | 12.6" |
| Height | 14" |
| Depth | 3.25" |
| Weight | 25.00 lb |
WHAT'S INCLUDED
- Heavy Duty Emergency Light
- Installation Instructions & Hardware
- 2 or 4 (Depending on Wattage Capacity Option) SLA Batteries - Must connect the batteries after installation (Located inside unit)
CONSTRUCTION
The EL-HD12 Heavy Duty Emergency Light has an Injection-molded, engineering-grade, 5VA flame retardant, high-impact thermoplastic construction housing.
ILLUMINATION
The EL-HD12 Industrial Emergency Light can be configured with (2) 7W, 9W, 12W, or 18W adjustable lamps. The unit is also available with no lamps that allows additional remote head lamps to be connected for optimal lighting.
EMERGENCY OPERATION
Upon failure of the normal utility power, an internal solidstate transfer switch automatically provides uninterrupted emergency operation for at least 90 minutes. The fully automatic solid-state, two-rate charger initiates battery charging to recharge a discharged battery in 24 hours.
BATTERY - BATTERY BACKUP
The EL-HD12 Emergency Light comes with maintenance-free 12V 12Ah rechargeable sealed lead acid batteries. 50W units are equipped with (2) 12V batteries and 100W units are equipped with (4) 12V batteries.
OPERATIONAL TEMPERATURE
| Temperature Ratings | |
| Series | Temperature |
| Standard Option | 25°C to 40°C / 77°F to 104°F |
| Expanded Temperature Rating | -9°C to 40°C / 15°F to 104°F |
REMOTE HEAD CAPABLE OPTION
The remote head capability option allows the EL-HD12 unit to supply power to multiple remote heads. The number of remote heads supported will vary depending on wattage model and remote head wattage. The remote heads would then operate on the same emergency mode as the standard units (see Emergency Operation Section).
ELECTRICAL COMPONENTS
Dual voltage input 120/277 VAC operation. LED display indicates AC/ON. An external push button test switch allows maintenance personnel to quickly determine the operational status of the unit. Unit offers surge protected, solid-state circuitry.
INSTALLATION
The EL-HD12 Industrial Emergency Light is suitable for wall installation. Back cover is designed with universal knockouts for multiple installation configurations. Unit includes side and top knockouts for conduit feed applications.
Mounting Configurations Explained
View Installation Instructions
DIMENSIONS
